Description
Features
- 6.5” / 165 mm performance midbass which combines outstanding sound quality with versatile physical integration options
- High efficiency and 2 Ohms technology for maximum power output of the amplifier
- Unique Cenosphere coated paper cone for precise and detailed sound reproduction
- High-tech polymer composite basket reinforced with glass beads for enormous rigidity and minimised ringing
- Specially shaped rubber surround for high linear cone excursion
- Polyurethane dustcap for optimised frequency response in the upper midrange area
- 1” / 25 mm voice coil ensures high power handling
- Automotive grade ProConnect connection terminal allows the use of conventional speaker cables or a fast, secure and fail-safe connection via optionally available WireKits
- Powerful magnet system for high efficiency and optimum impulse response
Technical data
| Power handling RMS / max. | 100 / 150 Watts | |
| Impedance | 2 Ω | |
| DC resistance | 1.8 Ω | |
| Frequency response | 60 Hz – 3,500 Hz | |
| Resonance frequency | 74 Hz | |
| Mechanical Q factor | 3.92 | |
| Electrical Q factor | 0.92 | |
| Total Q factor | 0.74 | |
| Compliance | 370 µm/N | |
| Equivalent air volume | 8.8 L | |
| Force factor | 3.5 Tm | |
| Sensitivity | 94 dB @ 2.83 V / 1m 88 dB @ 1W / 1m |
|
| Cone area | 133 cm² | |
| Moving mass | 12.5 g | |
| Cone material | Paper with Cenosphere coating | |
| Mechanical resistance | 1.48 kg/s | |
| Voice coil diameter | 25 mm | |
| Voice coil winding height | 11.3 mm | |
| Max. linear excursion | +/- 3.7 mm | |
| Outer diameter | 165 mm / 6.5″ | |
| Installation diameter | 142 mm / 5.59″ | |
| Installation depth | 60.7 mm / 2.39″ |
